Binding a Xamarin.Forms WebView to ReactiveUI View Model using Custom Type Converters

Jamil Geor

Sep 14, 2017 • 4 min read

Introduction

In this article, we will expand on our demo app, by displaying article content inside of a WebView after the user is navigated to the ArticleView.

To make things more interesting, because we are pulling in content from this blog, we will be using HTMLAgilityPack to strip out any unnecessary HTML that we don't want to be displayed inside of our app.

We'll also be utilising a ReactiveUI custom type converter to bind our WebView to raw HTML content.

At a high level our ArticleViewModel is going to do the following:

Download HTML from URL specified in the Article object that we are storing in our ViewModel
Cache the HTML content
Parse HTML to strip out unwanted tags, and fix other related issues
Map content to WebView

Setup

Install the HTMLAgilityPack NuGet package into all three projects i.e. Droid, iOS, and PCL projects. We'll be using this to clean up the HTML that we download from this blog.
https://www.nuget.org/packages/HtmlAgilityPack

Parsing HTML

A WebView can take two different data sources, the first being a website URL, and the second being a raw HTML string. In our case we want to use the second method, this is because we'd like to modify the HTML from the articles before we display the article in our View.

I won't go into the parsing code detail, but at a high level, you can see what is happening in the code snippet below.

public interface IHtmlParserService
{
    string Parse(string content, string baseUrl);
}

public class HtmlParserService : IHtmlParserService
{
    public string Parse(string content, string baseUrl)
    {
        var document = new HtmlDocument();

        document.LoadHtml(content);

        ReplaceRelativeUrls(document, baseUrl);

        RemoveRedundantElements(document);

        return document.DocumentNode.OuterHtml;
    }
    ...
}

The full source code for this class can be found here.

ViewModel

We'll now setup our ViewModel. The first thing we need to do is create a new property that the View will bind to called Content. This property will simply store the parsed HTML content that we want to display in our View.

string _content;
public string Content {
    get => _content;
    set => this.RaiseAndSetIfChanged(ref _content, value);
}

We now need to implement our methods for fetching our content from the blog, and also the method that we'll use to map the parsed HTML content to our Content property.

IObservable<string> LoadArticleContent()
{
    return BlobCache
        .LocalMachine
        .GetOrFetchObject<string>
        (CacheKey,
         async () =>
         await _articleService.Get(Article.Url), CacheExpiry);
}

void MapContentImpl(string content)
{
    Content = _htmlParserService.Parse(content, Configuration.BlogBaseUrl);
}

We now want to call our new LoadArticleContent method from inside of our constructor to initialize the Content property that the View will be bound to.

public ArticleViewModel(IScreen hostScreen, Article article)
{
    ...

    LoadArticleContent()
        .ObserveOn(RxApp.MainThreadScheduler)
        .Catch<string, Exception>((error) => {
            this.Log().ErrorException($"Error loading article {Article.Id}", error);
            return Observable.Return("<html><body>Error loading article.</body></html>");
        })
        .Subscribe(MapContentImpl);
}

The above code simply does the following:

Call LoadArticleContent method
Ensure that the following code runs on the main UI thread
Catch any exceptions, and return an error message
Call the MapContentImpl method and pass the result of LoadArticleContent or the Error message

Custom Type Converters

Now that our ViewModel is all setup, we just need to bind the Source property of our WebView to our Content property on our ViewModel.

Because the Source property of a WebView uses a type that doesn't have a default binding converter provided by ReactiveUI, we'll need to create our own.

To do this we just need to create a class that implements the IBindingTypeConverter interface.

public class HtmlBindingTypeConverter : IBindingTypeConverter, IEnableLogger
{
    public int GetAffinityForObjects(Type fromType, Type toType)
    {
        return fromType == typeof(string) && toType == typeof(WebViewSource) ? 100 : 0;
    }

    public bool TryConvert(object from, Type toType, object conversionHint, out object result)
    {
        try
        {
            result = new HtmlWebViewSource { Html = (string)from };
            return true;
        }
        catch (Exception error)
        {
            this.Log().ErrorException("Problem converting to HtmlWebViewSource", error);
            result = null;
            return false;
        }
    }
}

The GetAffinityForObjects method simply validates that a the from and to properties can be converted by our type converter. If it can't then we should return 0 otherwise, we should return any number greater than 0. If there are two converters that can handle the types that are passed to it, then the number returned by this method will determine which one is selected.

The TryConvert method does the actual conversion from one type to another.

You can read more about type converters here:
https://reactiveui.net/docs/handbook/data-binding/type-converters

Now that we have created our type converter, we need to register it with the Splat dependency resolver. We do this in our AppBootstrapper class.

public class AppBootstrapper : ReactiveObject, IScreen
{
...
    private void RegisterParts(IMutableDependencyResolver dependencyResolver)
    {
        ...
        dependencyResolver.RegisterConstant(new HtmlBindingTypeConverter(), typeof(IBindingTypeConverter));
    }
...
}

Binding the View

All we need to do now is setup the binding in our view.

public partial class ArticlePage : ContentPage, IViewFor<ArticleViewModel>
{
    readonly CompositeDisposable _bindingsDisposable = new CompositeDisposable();

    ...
    protected override void OnAppearing()
    {
        base.OnAppearing();

        this.OneWayBind(ViewModel, vm => vm.Content, v => v.ArticleContent.Source).DisposeWith(_bindingsDisposable);
    }
    ...
}
